S35 Beechcraft Bonanza
The Model S35 Bonanza
Features: Trapezoidal long rear windows, Long-chord stabilators, Stinger tail cone, Recessed wing lights, Single, throw-over control yoke, Vernier engine and mixture controls, Gear handle on right, flap on left, Landing lights on nose and nosewheel strut, Gear-driven alternator, Overhead ventilation system, Extended aft baggage area.
Common Options: Long-range fuel (two 40-gallon tanks), Large baggage door, Engine upgrades, Forward facing "family" 5th and 6th seats in aft baggage area, Tip tanks, Improved cabin ventilation system, Dual control yoke, Avionics upgrades
Speeds (kts): Max Speed - 184, Recommended Cruise - 178, Stall Speed (dirty) - 54, Best Rate - 96, Best Angle - 76, Cruise Climb - 107, Glide - 105
Manufactured: 1964-1965, 667 made, D-7140; D-7310 thru D-7976 except D-7859
Standard Engine: TCM IO520B, 285HP, 1,700 TBO
Weights: Gross 3300, Empty 1915, Useful 1270, Payload (FF) 970
Rate Of Climb (fpm): 1,150
Service Ceiling (ft): 19,200
Fuel (Gal): 50 Range (NM): 535
Distances (ft): Takeoff ground roll 1050, Over 50 foot obstacle 1260 - Landing ground roll 650, Over 50 foot obstacle 1100
Exterior Dimensions: Length - 26'5" Height - 7'7" Wingspan - 33'"6
Cabin Dimensions: Length - 8'6", Height - 4'2", Width - 3'6", Door 37" x 36"
Baggage: Capacity - 270 (lbs), Cubic Volume - 16.5 (cu.ft.), Door - 22.5" x 18.5"
Wing Loading: 18.23 lbs/sq ft
Power Loading: 11.58 lbs/hp
